tk-uyz3 type series capacitance level meter
http://www.ahdqjt.com time: 10/28/10 08:41
overview:
tk-uyz3 type series capacitance level meter is used to test the level of open container or container under pressure, or continuous measure the level of conductive and non-conductive liquid, powder and so on. the change of material level will be converted to the change of capacitances, transformed into 4 ~ 20ma current through the dedicated circuit to be outputted.
|
model name |
tk-uyz-3 type series capacitance level meter |
|
measuring principle |
electrode and the metal container wall to form a capacitor |
|
measuring range |
500mm ～ 10000mm |
|
operating temperature |
-200 ℃ ~200 ℃ |
|
working pressure |
2.5mpa |
|
explosion-proof class |
d ⅱ bt4 ia ⅱ ct4 ～ 6 |
|
output signal |
4~20 ma （double wire system） |
|
installation way |
flange jb/tb1-94pn25 dn40 |
|
measuring accuracy |
non-ex 1.0 ex 1.5 |
：
：meters
